FX Pump
FX PUMP FOR SALE
FX series pump are designed for pool owners to heat their swimming pool so that they can use it all year round. Thermo Pools supply AstralPool’s FX pumps (AstralPool is Australia’s renowned swimming pool equipment manufacturer since the 1990’s).
Why FX Series Pump?
FX series pumps are intentionally made for the swimming pools that are above the ground level or if you need a pump for heating systems. They are dependable heat pumps as they provide efficient performance without making noise (i.e. they are silent) – these are the main features that you look for when buying a pool heat pump along with all other requirements that you need to meet for the swimming pool equipment.
The FX pumps are designed and manufactured to render the power required to transfer huge volume of water around while producing very small operating sound. To ensure maximum reliability especially in high-pressure situations, a non-return valve is integrated within the pump, which facilitates elimination of reverse rotation of the impeller.
FEATURES
- FX series pumps come in six diverse sizes to meet your equipment requirements.
- Hair & lint pot is not required.
- It is intentionally made so that it can be used as a booster pump where flooded suction can be performed.
- Its operation is tranquil.
SPECIFICATIONS
Model |
Voltage |
Full Load Amps |
Phase |
Input |
Full Load |
Flow Rate @ 8 m/h |
Conns “mm” |
FX 140 Flooded Suction Pump 0.50 HP |
240 |
2.9 |
Single |
650 |
2.75 |
140 lpm |
40/50 |
FX 190 Flooded Suction Pump 0.75 HP |
240 |
3.2 |
Single |
822 |
3.47 |
190 lpm |
40/50 |
FX 250 Flooded Suction Pump 1.00 HP |
240 |
4.3 |
Single |
1015 |
4.38 |
250 lpm |
40/50 |
FX 340 Flooded Suction Pump 1.50 HP |
240 |
6.6 |
Single |
1617 |
7.10 |
340 lpm |
40/50 |
FX 520 Flooded Suction Pump 2.00 HP |
240 |
8.3 |
Single |
1900 |
520 lpm |
520 lpm |
40/50 |
